OMRON LIMIT SWITCH WITH SHORT LEVER AND ROLLER

The Omron D3V-165-1C25 is a high-quality miniature limit switch designed for switching and detection applications where precise operation, good load capacity, and a compact design are required. Thanks to its short lever with roller design, it is particularly suitable for mechanisms with repeated actuation, closing systems, household appliances, light machinery, automation systems, and equipment where the contact must be activated by a cam, guide, or controlled mechanical movement.

The D3V-165-1C5 belongs to Omron?s D3V series. It is a 16A version with SPDT changeover contact configuration, short roller lever, and 6.3mm Faston terminals. It stands out for its balance of compact size, electrical endurance, and durability, making it a widely used solution whenever a robust microswitch is needed for frequent operation.

One of its main strengths is its long mechanical life, which in the D3V series reaches a minimum of 10,000,000 operations, together with a minimum electrical life of 100,000 operations for the D3V-16 version. In addition, it offers a minimum insulation resistance of 100M Ohms at 500VDC, dielectric strength of up to 2000VAC for 1 minute between live parts and ground, and an IP40 degree of protection, features that help improve overall reliability in demanding operating environments.

This Omron limit switch is designed to handle loads of up to 16A at 250VAC, and it also supports operation at 125VDC and 250VDC at reduced current levels. Its compact construction makes integration easier in equipment where space is limited, while the roller lever reduces friction wear and promotes smoother actuation over moving surfaces.

For all these reasons, the Omron D3V-165-1C5 is an excellent choice for anyone looking for a reliable, compact limit switch with good switching capacity, backed by Omron?s experience in electromechanical components and by a series widely used in industrial and control applications.

Technical Features:

- Contact configuration: 1 changeover contact (SPDT)
- Actuator: Short lever with roller
- Connection: 6.3mm Faston terminals
- Rated current: 16A
- Rated AC voltage: 250VAC
- Degree of protection: IP40

Datasheet

Price : 2,47 €

Retail Price (VAT include) : 2,99 €

Add to Cart
